Kondensor Heat Exchanger Sa210 Pipa Baja Khusus
Rincian produk
sa210 pipa baja khusus
,tabung baja stainless bersirip sa210
,pipa baja khusus iso
Pipa Berbasis Karbon Al Bahan Tabung Berujung Rendah untuk Penukar Panas Kondensor
1Pambuka:
Pipa Berbasis Karbon Al Bahan Tabung Berujung Rendah untuk Penukar Panas Kondensor | |
| Aplikasi | Boiler pembangkit listrik, boiler pemanasan, fin economizer boiler industri, preheater udara pipa panas, boiler suhu limbah dan boiler baja, petrokimia, kimia dan berbagai industri |
| Bahan pipa dasar | Karbon, baja paduan, tabung stainless steel |
| Bahan sirip | Aluminium atau tembaga |
| Jenis pipa dasar | Tanpa jahitan, dilas |
| Bentuk tabung berdaun | Spiral |
| OD pipa dasar | 25 mm-168 mm |
| WT pipa dasar | 1-10 mm |
| Tinggi sirip | 8 mm- 20mm |
| WT dari sirip | 0.8mm- 5mm |
| Jarak sirip | 2.0mm- 20mm |
| Panjang area kosong | Menurut permintaan pelanggan. |
Bahan:baja karbon, baja tahan karat, tembaga, tembaga-sink, tembaga-nikel, aluminium
Diameter tabung dasar dari tabung sirip rendah tembaga untuk penukar panas: 12,7-25,4 mm
Ketebalan dinding tabung dasar 1,65-3,0 mm
Ketebalan sirip adalah 0,3-0,5 mm
Jarak sirip 0,9-1,5 mm
Tinggi sirip 0,9-1,3 mm
Fitur:
Rasio perpindahan panas maksimum tabung sirip rendah akan meningkat 2.5 to 3 times to compare with plain bare tubes and also it can be not only reduced the cost for new equipment or retrofitting of old equipments but also save the size or weight of new equipment from the beginning stage of basic design.
Keuntungan Torich:
1Pemilihan bahan berkualitas tinggi
2. Dukungan non-standar disesuaikan
3. Desain ilmiah dan wajar
4. Kehidupan layanan yang panjang
Aplikasi:
Penukar panas untuk aplikasi pendinginan dan pemanasan cairan dan gas,termasuk air,minyak,uap dan udara serta untuk kondensasi, penguapan. Kondensator penukar panas pipa ganda,Absorber kulkas pendingin,Absorpsi kulkas pendingin penguap, jatuh film penguap,Absorpsi kulkas pendingin kondensator
Bahan:baja karbon, baja tahan karat, tembaga, tembaga-sink, tembaga-nikel, aluminium
Diameter tabung dasar 12,7-25,4 mm
Ketebalan dinding tabung dasar 1,65-3,0 mm
Ketebalan sirip adalah 0,3-0,5 mm
Jarak sirip 0,9-1,5 mm
Tinggi sirip 0,9-1,3 mm
Low finned tubes Low-finned tube/threaded tube/internally threaded tubeLow-finned threaded copper tube heat exchanger air conditioner copper tube red copper finned tube internal and external thread high-efficiency evaporator tube/Efficient tube /Corrugated Tubes/LHT Low Fin Tubes
Fitur:
Rasio perpindahan panas maksimum tabung sirip rendah akan meningkat 2.5 to 3 times to compare with plain bare tubes and also it can be not only reduced the cost for new equipment or retrofitting of old equipments but also save the size or weight of new equipment from the beginning stage of basic design.
Keuntungan Torich:
1Pemilihan bahan berkualitas tinggi
2. Dukungan non-standar disesuaikan
3. Desain ilmiah dan wajar
4. Kehidupan layanan yang panjang
Aplikasi:
Penukar panas sirip tabung tembaga dapat digunakan untuk mendinginkan dan memanaskan cairan dan gas,termasuk air,minyak,uap dan udara serta untuk kondensasi,pengampuran.Absorber kulkas pendingin, boiler fined tube economizer, Absorpsi kulkas pendingin evaporator, jatuh film evaporator, Absorpsi kulkas pendingin kondensator
6.KONTROL KUALITAS:
1. Inspeksi bahan baku yang masuk
2. Pengelompokan bahan baku untuk menghindari campuran kelas baja
3. Pemanasan dan Hammering End untuk Cold Drawing
4. Menggambar dingin dan penggulung dingin, pemeriksaan di jalur
5Pengolahan panas, +A, +SRA, +LC, +N, Q+T
6. Straightening-Motong ke panjang yang ditentukan-Selesai Pengukuran Inspeksi
7. Pengujian mekanik di laboratorium sendiri dengan kekuatan tarik, kekuatan hasil, elongasi, kekerasan, dampak, mikrostruktur dll
8- Kemasan dan Stoking.
7.Pameran produk:
8. FAQ
Bagaimana kapasitas produksi Anda?
1.2000 ton kapasitas produksi bulanan, 5000 ton kapasitas perdagangan bulanan
2Pengiriman cepat dan tepat waktu.
Apakah Anda menyediakan sampel tabung baja karbon tanpa jahitan?
Ya, kami bisa menawarkan sampel gratis tetapi perlu membayar biaya pengiriman.
Apakah Anda perusahaan perdagangan atau produsen?
Seorang penemu profesional pipa baja bahan, produsen dan penyedia solusi
-
