Pipa Stainless Steel 100mm dengan Nikel, Pipa Stainless Steel 200/201
Rincian produk
stainless steel putaran tabung
,diameter besar tabung baja stainless
ASTM B161 Pipa dan tabung nirkabel tanpa jahitan untuk penukar panas dan kondensor
Aplikasi: Tabung baja untuk penukar panas dan kondensator
Jangkauan ukuran:O.D.:6-127mm W.T.:1-30mm L: sesuai dengan kebutuhan pelanggan
Kelas baja:
UNS N02200 Nikel
UNS N02201 Nikel rendah karbon
Pembuatan:
Ditarik dingin tanpa jahitan.
Metode pengujian:
Uji hidrostatik
| Tabel 2 Persyaratan kimia | ||
| Komposisi Kimia | Komposisi, % | |
| Elemen | Nikel (UNS N02200) | Nikel rendah karbon (UNS N02201) |
| Tidak, sebentar. | 99.00 | 99.00 |
| Cu | 0.25 | 0.25 |
| Fe | 0.40 | 0.40 |
| Mn, maksimal | 0.35 | 0.35 |
| C,max | 0.15 | 0.02 |
| Ya, maksimal. | 0.35 | 0.35 |
| S,max | 0.01 | 0.01 |
Mesin dan Inspeksi:
Uji ketegangan
Sifat-sifat tarik
Uji hidrostatik atau uji listrik tidak merusak
Analisis Kimia
Dokumen referensi:
Spesifikasi ASTM B829 untuk persyaratan umum untuk nikel dan paduan nikel pipa dan tabung tanpa jahitan
ASTM E426 Praktek untuk Pemeriksaan Elektromagnetik (Eddy-Current) dari Tubular tanpa jahitan dan Las
Produk, baja tahan karat austenit dan paduan serupa
ASTM E571 Praktek untuk Pemeriksaan Elektromagnetik (Eddy-Current) dari Tubular tanpa jahitan dan Las
Produk
-
