ASTM A270 Tabung Dilas Mulus 50mm Stainless Steel TP304, TP304L, TP316, TP316L
Rincian produk
stainless steel putaran tabung
,diameter besar tabung baja stainless
ASTM A270 Selang Saniter Austenitic dan Ferritic/Austenitic Stainless Steel Tanpa Jahit dan Las
Aplikasi: tabung sanitasi di industri susu dan makanan, dan memiliki permukaan khusus
Jangkauan ukuran:O.D.: 4,0-305mm W.T.:1-50mm L: sesuai dengan kebutuhan pelanggan
Persyaratan Kimia
| Kelas: | TP304 | TP304L | Aku tidak tahu. | TP316 | TP316L | Aku tidak tahu. | Aku tidak tahu. | Aku tidak tahu. |
| UNS | S30400 | S30403 | S31254 | S31600 | S31603 | N08926 | N08367 | S31803 |
| C, maksimal | 0.08 | 0.035 | 0.020 | 0.08 | 0.035 | 0.020 | 0.030 | 0.030 |
| Mn, maksimal | 2.00 | 2.00 | 1.00 | 2.00 | 2.00 | 2.00 | 2.00 | 2.00 |
| P, maksimal | 0.045 | 0.045 | 0.030 | 0.045 | 0.045 | 0.030 | 0.040 | 0.030 |
| S, maksimal | 0.030 | 0.030 | 0.010 | 0.030 | 0.030 | 0.010 | 0.030 | 0.020 |
| Ya, maksimal. | 1.00 | 1.00 | 0.80 | 1.00 | 1.00 | 0.50 | 1.00 | 1.00 |
| Tidak | 8.0-11.0 | 8.0-12.0 | 17.5-18.5 | 10.0-14.0 | 10.0-15.0 | 24.0-26.0 | 23.5-25.5 | 4.5-6.5 |
| Cr | 18.020.0 | 18.020.0 | 19.520.5 | 16.018.0 | 16.0-18.0 | 19.0-21.0 | 20.0-22.0 | 22.0-23.0 |
| Mo | Aku tidak tahu. | Aku tidak tahu. | 6.0-6.5 | 2.003.00 | 2.00-3.00 | 6.0-7.0 | 6.0-7.0 | 3.0-3.5 |
| Tidak | Aku tidak tahu. | Aku tidak tahu. | 0.18-0.22 | Aku tidak tahu. | Aku tidak tahu. | 0.15-0.25 | 0.18-0.25 | 0.140.20 |
| Tembaga | Aku tidak tahu. | Aku tidak tahu. | 0.50-1.00 | Aku tidak tahu. | Aku tidak tahu. | 0.50-1.5 | 0.75 maksimal | Aku tidak tahu. |
| Kelas: | Aku tidak tahu. | Aku tidak tahu. | 2003 |
| UNS | S32205 | S32750 | S32003 |
| C, maksimal | 0.030 | 0.030 | 0.030 |
| Mn, maksimal | 2.00 | 1.20 | 2.00 |
| P, maksimal | 0.030 | 0.035 | 0.030 |
| S, maksimal | 0.020 | 0.020 | 0.020 |
| Ya, maksimal. | 1.00 | 0.80 | 1.00 |
| Tidak | 4.5-6.5 | 6.0-8.0 | 3.0-4.0 |
| Cr | 22.0-23.0 | 24.0-26.0 | 19.5-22.5 |
| Mo | 3.0-3.5 | 3.0-5.0 | 1.5-2.0 |
| Tidak | 0.14-0.20 | 0.24-0.32 | 0.14-0.20 |
| Tembaga | Aku tidak tahu. | 0.50 maksimal | Aku tidak tahu. |
| Kelompok | Ukuran, Diameter luar, in ((mm) | Variasi yang diizinkan dalam Diameter Luar, di [mm]Over Uder | Perbedaan yang diizinkan dalam WT, % | Perbedaan yang diizinkan dalam panjang potong, dalam [mm] | |
| 1 | 1.000(25.4) dan di bawah | ± 0,005[0,13] | ± 15 | 1/8[3.2] | 0 |
| 2 | Lebih dari 1 ((25.4) sampai 2 ((50.8) | ± 0,005[0,20] | ± 10 | 1/8[3.2] | 0 |
| 3 | Lebih dari 2 (50.8) sampai 76.2) | ± 0,010[0,25] | ± 10 | 1/8[3.2] | 0 |
| 4 | Lebih dari 3 ((76.2) sampai 4 ((101.6) | ± 0,015[0,38] | ± 10 | 1/8[3.2] | 0 |
| 5 | Lebih dari 3 ((101.6) sampai 51⁄2 ((139.7) eksklusif | ± 0,015[0,38] | ± 10 | 3/16[4.8] | 0 |
| 6 | 5 1⁄2 ((139.7) sampai 8 ((203.2) eksklusif | ± 0,030[0,76] | ± 10 | 3/16[4.8] | 0 |
| 7 | 8 ((203.2) sampai 12 ((304.8) | ± 0,050[1.27] | ± 10 | 3/16[4.8] | 0 |
| Kelas | UNS | Kekuatan tarik | Kekuatan hasil | Perpanjangan dalam 2in atau50 mm Min % | Kekerasan Rockwell |
| TP304 | S30400 | 75 ((515) | 30 ((205) | 35 | B90 |
| TP304L | S30403 | 70 ((485) | 25 ((170) | 35 | B90 |
| TP316 | S31600 | 75 ((515) | 30 ((205) | 35 | B90 |
| TP316L | S31603 | 70 ((485) | 25 ((170) | 35 | B90 |
|
| S31803 | 90 ((620) | 65 ((450) | 25 | C30.5 |
| 2205 | S32205 | 95 ((655) | 70 ((485) | 25 | C30.5 |
| 2507 | S32750 | 116 ((800) | 80 ((550) | 15 | C32 |
| 2003 | S32003 | 90 ((620) | 65 ((450) | 25 | C30 |
-
