Pipa Baja Struktural 12000mm Panjang, Pipa Baja Karbon Gost8733 Gost8734
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
TS16949 , KR , RINA , DNV , GL , PED
Nomor Model:
Gost8733 Gost8734
Properti Perdagangan
Jumlah Pesanan Minimum:
5MT
Harga:
USD600-900 per ton
Kemampuan Penyediaan:
6000MT/Month
Ringkasan Produk
pipa baja struktural, Gost8733 Gost8734 pipa baja karbon Gost8733 Gost8734 Pipa dingin dan panas tanpa jahitan Aplikasi: Untuk struktural, transportasi cairan, boiler dll Jangkauan ukuran:O.D.:6-350m W.T.:1-50mm L:max12000mm Kelas baja Kekuatan tarik σв, MPa (kg/mm) Kekuatan output, σт, MPa, (kg/mm) ...
Rincian produk
Menyoroti:
Tabung Baja struktural
,structural steel square tubing
Dimension::
6-168mm * 1-15mm * 12000mm
Application::
Untuk Struktural, transportasi cair, boiler dll
Grade::
10, 20, 35, 45, 10G2, 15X, 20X
Section Shape::
Bulat
Material::
Baja karbon
Product Name::
pipa baja struktural
Deskripsi Produk
pipa baja struktural, Gost8733 Gost8734 pipa baja karbon
Gost8733 Gost8734 Pipa dingin dan panas tanpa jahitan
Aplikasi: Untuk struktural, transportasi cairan, boiler dll
Jangkauan ukuran:O.D.:6-350m W.T.:1-50mm L:max12000mm
| Kelas baja | Kekuatan tarik σв, MPa (kg/mm) | Kekuatan output, σт, MPa, (kg/mm) | Perpanjangan, δs, % | Kekerasan Brinell (disediakan dinding ketebalan lebih dari 10 mm) | |
| Min | Cetakan diameter Mm, menit | Jumlah kekerasan HB,max | |||
| 10 ((St37.00) | 343 ((35) | 206 ((21) | 24 | 5.1 | 137 |
| 20 ((St44.00) | 412 ((42) | 245 ((25) | 21 | 4.8 | 156 |
| 35 | 510 ((52) | 294 ((30) | 17 | 4.4 | 187 |
| 45 | 589 ((60) | 323 ((33) | 14 | 4.2 | 207 |
| 10G2 | 422 ((43) | 245 ((25) | 22 | 4.3 | 197 |
| 15X | 412 ((42) | - | 19 | 4.5 | 179 |
| 20X | 431 ((44) | - | 17 | 4.5 | 179 |
| 40X | 618 ((63) | - | 14 | 4.1 | 217 |
| 30XGCA | 491 ((50) | - | 18 | 4 | 229 |
| 15XM | 431 ((44) | 226 ((23) | 21 | - | - |
Gost8733 Gost8734 Pipa dingin dan panas tanpa jahitan
Aplikasi: Untuk struktural, transportasi cairan, boiler dll
Jangkauan ukuran:O.D.:6-350m W.T.:1-50mm L:max12000mm
| Kelas baja | Kekuatan tarik σв, MPa (kg/mm) | Kekuatan output, σт, MPa, (kg/mm) | Perpanjangan, δs, % | Kekerasan Brinell (disediakan dinding ketebalan lebih dari 10 mm) | |
| Min | Cetakan diameter Mm, menit | Jumlah kekerasan HB,max | |||
| 10 ((St37.00) | 343 ((35) | 206 ((21) | 24 | 5.1 | 137 |
| 20 ((St44.00) | 412 ((42) | 245 ((25) | 21 | 4.8 | 156 |
| 35 | 510 ((52) | 294 ((30) | 17 | 4.4 | 187 |
| 45 | 589 ((60) | 323 ((33) | 14 | 4.2 | 207 |
| 10G2 | 422 ((43) | 245 ((25) | 22 | 4.3 | 197 |
| 15X | 412 ((42) | - | 19 | 4.5 | 179 |
| 20X | 431 ((44) | - | 17 | 4.5 | 179 |
| 40X | 618 ((63) | - | 14 | 4.1 | 217 |
| 30XGCA | 491 ((50) | - | 18 | 4 | 229 |
| 15XM | 431 ((44) | 226 ((23) | 21 | - | - |
