Presisi Baja Tabung GOST9567 10 20 35 45 40X 30ХГСА Alloy Steel Tabung
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
ISO 9001 ISO 14001 EN 10204.3.1 TS 16949
Nomor Model:
GOST9567
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
USD 600-1200 ton
Kemampuan Penyediaan:
60000tons per tahun
Ringkasan Produk
GOST9567 10 20 35 45 40X 30ХГСА Pipa Baja-pipa Baja presisi GOST9567 Tabung baja presisi TORICH mengkhususkan diri dalam manufakturtabung baja presisi yang ditarik dingin sesuai dengan standar teknis GOST9567. tabung baja karbon presisi biasanya diproduksi dari billet bulat ke tabung berongga...
Rincian produk
Menyoroti:
Presisi pipa baja
,precision pipes and tubes
Material:
Baja Karbon dan Baja Paduan
Steel Grade:
10 20 35 45 40X
Standard:
GOST9567
Shape:
Bulat
Applications:
Otomotif, teknik mesin, suku cadang mobil dll.
Size Range:
OD: 6-168mm WT: 1-15mm L: max12000mm
Production Method:
Digambar Dingin Tanpa Mulus
Deskripsi Produk
GOST9567 10 20 35 45 40X 30ХГСА Pipa Baja-pipa Baja presisi
GOST9567 Tabung baja presisi
TORICH mengkhususkan diri dalam manufakturtabung baja presisi yang ditarik dingin sesuai dengan standar teknis GOST9567.
tabung baja karbon presisi biasanya diproduksi dari billet bulat ke tabung berongga,kemudian setelah beberapa proses tarik dingin ke diemenion akhir dengan toleransi ukuran target dan sifat mekanik.
Aplikasiftabung presisi baja karbon:
Otomotif, Teknik Mesin, Bagian Otomotif dll.
Berbagai ukurantabung baja tanpa jahitan presisi yang ditarik dingin:
O.D.:6-168mm W.T.:1-15mm L:max12000mm
Komposisi kimia ((%, maksimum) untuk tabung presisi baja karbon:
| Kelas baja | C | Ya. | Mn | Cr | Tidak | Mo | S | P | Cu |
| 10 | 0.07-0.14 | 0.17-0.37 | 0.35-0.65 | 0.15 | 0.3 | - | - | - | - |
| 20 | 0.17-0.24 | 0.17-0.37 | 0.35-0.65 | 0.25 | 0.25 | - | 0.03 | 0.025 | 0.3 |
| 35 | 0.32-0.40 | 0.17-0.37 | 0.50-0.80 | 0.25 | 0.3 | - | 0.04 | 0.035 | 0.3 |
| 45 | 0.42--0.45 | 0.17-0.37 | 0.50-0.80 | 0.25 | - | - | - | - | - |
| 40X | 0.36-0.44 | 0.17-0.37 | 0.50-0.80 | 0.80-1.10 | 0.3 | - | 0.035 | 0.035 | 0.3 |
| 30XHSA | 0.28-0.34 | 0.90-1.20 | 0.80-1.10 | 0.80-1.10 | 0.3 | - | 0.005 | 0.025 | - |
Sifat Mekanis:
| Kelas baja | Kekuatan tarik, N/mm2 (min) | Kekuatan hasil, N/mm 2 (min) | Perpanjangan, % ((menit) |
| 10 | 343 | 206 | 24 |
| 20 | 412 | 245 | 21 |
| 35 | 510 | 294 | 17 |
| 45 | 589 | 323 | 14 |
| 40X | 618 | - | 14 |
| 30XHSA | 491 | - | 18 |
Produksi dan Pemeriksaan Kualitas:
