Name: ST52 Seamless Steel Triangle Tube for Agricultural Shafts
Brand: TORICH INTERNATIONAL LIMITED
SKU: Triangle Pipe ST52
Price: 950.00 USD
Availability: InStock

Rumah > Produk > tabung baja presisi >

ST52 Seamless Steel Triangle Tube for Agricultural Shafts

ST52 seamless steel tube

agricultural shaft steel tube

precision seamless triangle tube

Place of Origin:

Zhejiang/China

Nama merek:

TORICH

Sertifikasi:

ISO9001 ISO 14001 TS16949

Model Number:

Triangle Pipe ST52

Hubungi Kami

Minta Kutipan

ST52 Seamless Steel Triangle Tube for Agricultural Shafts

Rincian produk

Application:

Agricultural Shafts

Outer diameter(round):

30 - 426 mm,

Thickness:

2 - 100 mm,

Sertifikasi:

API,CE,ISO,ISO9001-2008,ISO9001

Technique:

Cold Drawn,Hot Rolled,Cold Rolled,ERW,Hot Rolled/Cold Drawn

Section shape:

Round,Rectangular

Grade group:

ST35-ST52

Length:

6M or as requirement,As customer's require,8m,5.8m,2.5-8m

Menyoroti:

ST52 seamless steel tube

agricultural shaft steel tube

precision seamless triangle tube

Syarat Pembayaran & Pengiriman

Minimum Order Quantity

1Ton

Harga

800-1100USD/Ton

Packaging Details

In bundles or in wooden boxes.

Delivery Time

20-30days upon products

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

60000 Ton/Tons per Year

Produk terkait

video

Incoloy 825 Pipa tanpa jahitan paduan berbasis nikel untuk desalinasi

Dapatkan Harga Terbaik

video

Pipa Baja Las Listrik ASME SA513 Pipa Baja Karbon Las Untuk Mekanik

Dapatkan Harga Terbaik

Pipa Gergaji Baja Karbon ASME SA139 Pipa Las Spiral Baja Karbon Untuk Industri Otomotif

Dapatkan Harga Terbaik

video

Tabung Baja Karbon Q345 OD 250mm Hidrolik Dingin

Dapatkan Harga Terbaik

Hubungi Kami

86-574-88086983

Hubungi Sekarang

Deskripsi Produk

Triangle Pipe Lemon Shape Alloy Seamless Steel Tube For Agricultural Shafts

Product Specifications

Attribute	Value
Application	Agricultural Shafts
Outer diameter (round)	30 - 426 mm
Thickness	2 - 100 mm
Certification	API, CE, ISO, ISO9001-2008, ISO9001
Technique	Cold Drawn, Hot Rolled, Cold Rolled, ERW, Hot Rolled/Cold Drawn
Section shape	Round, Rectangular
Grade group	ST35-ST52
Length	6M or as requirement, As customer's require, 8m, 5.8m, 2.5-8m

Material

The ST52 triangle pipe is a seamless, high-strength structural steel tube characterized by its uniform "lemon" (triangular) cross-section. Manufactured through hot extrusion and precision cold drawing, it delivers excellent dimensional accuracy, smooth internal surfaces, and superior mechanical properties suitable for demanding agricultural shaft applications.

Detailed Specifications

Shape: Equilateral triangular ("lemon") cross-section
Grade: ST52 (per EN 10210/10219)
Production Method: Hot extrusion + cold drawing (seamless)
Dimensions:
- Side length (a): 30 mm-100 mm (customizable)
- Wall thickness (t): 2 mm-8 mm
- Length: 3 m-12 m (standard)
Surface Finish: Mill finish or optional black oxide coating
Tolerance: ±0.2 mm on side length; ±0.15 mm on thickness

Chemical Composition

Grade	C (max %)	Si (max %)	Mn (max %)	P (max %)	S (max %)	Standard
ST52	0.22	0.50	1.60	0.035	0.035	EN 10210/10219
S355JR	0.22	0.55	1.60	0.035	0.035	EN 10025-2
Q345B	0.20	0.50	1.70	0.045	0.045	GB/T 1591
A572 Grade 50	0.23	0.40	1.35	0.035	0.040	ASTM A572/A572M
A106 Grade B	0.29	0.45	1.06	0.025	0.015	ASTM A106/A106M

Mechanical Properties

Grade	Yield Strength (MPa)	Tensile Strength (MPa)	Elongation (%)	Standard
ST52	≥355	510-680	≥22	EN 10210/10219
S355JR	≥355	470-630	≥20	EN 10025-2
Q345B	≥345	470-630	≥20	GB/T 1591
A572 Grade 50	≥345	450-620	≥18	ASTM A572/A572M
A106 Grade B	≥240	415-550	≥30	ASTM A106/A106M

Key Features

High Strength-to-Weight Ratio: Optimized alloy chemistry delivers excellent load-bearing capacity at reduced weight.
Seamless Integrity: Manufactured without weld seams for uniform stress distribution and fatigue resistance.
Dimensional Precision: Tight tolerances ensure consistent fit and alignment in shaft assemblies.
Surface Quality: Smooth internal/external walls minimize wear on bearings and seals.
Corrosion Resistance: Optional coatings or post-treatments extend service life in harsh agricultural environments.

Applicable Standards

ASTM: ASTM A572/A572M, ASTM A106/A106M
EN: EN 10210, EN 10219, EN 10025-2
GOST: GOST 8732-78 (seamless tubes)
JIS: JIS G3444 (carbon steel tubes)
GB: GB/T 12771, GB/T 8162

Application Domains

Agricultural Machinery Shafts

Tractor Drive Shafts: Transmit torque from engine to drivetrain via triangular spline fittings.
Combine Harvester Shafts: Provide power take-off interfaces for header and threshing units.
Plow Frame Connectors: Act as rigid couplings between plow beams and hydraulic actuators.
Seeder Drive Shafts: Ensure precise, backlash-free rotation for seed metering assemblies.
Rotary Tiller Shafts: Deliver robust torque to tillage tines in corrosive soil conditions.

Frequently Asked Questions

Q: Are you trading company or manufacturer?

A: Manufacturer, also can do trading.

Q: How long is your delivery time?

A: Generally speaking, it is 10-15 days if the goods are in stock, or it is 30-40 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples? Is it free or extra?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment?

A: Payment≤2000USD, 100% in advance. Payment≥2000USD, 30% T/T in advance, balance before shipment. If you have another question, please feel free to contact with me.
