Resistensi Oksidasi Superalloy Inconel Pipe 0,299 lbs / in3 8,28 g / cm3 980 ℃
Rincian produk
inconel 600 tube
,inconel 601 tube
Inconel Steel Tue diproduksi dengan Inconel Alloy Steel GradeInconelX-750
Komponen mekanik
C: ≤ 0.08
Cr:14.0-17.0
Ni+Co: ≥70.0
Al:0.40-1.00
Ti:2.25-2.75
Fe:5.00-9.00
Nb+Ta:0.70-1.20
Co:1.00max
Mn:1.00max
Si:0.50max
S:0.010max
Cu:0.50max
P:0.015max
Data untuk sifat fisik material:
Desity: 0,299lbs/in3,8.28g/cm3
Konduktivitas termal InconelX-750
| θ/°C | 50 | 100 | 300 | 500 | 900 |
| λ/(W/(m·°C)) | 14.7 | 15.9 | 20.1 | 25.1 | 37.3 |
Koefisien ekspansi garis InconelX-750
| θ/°C | 20 ¢ 200 | 20 ¢ 300 | 20 ¢ 400 | 20 ¢ 500 | 20 ¢ 600 | 20 ¢ 700 | 20 ¢ 800 |
| α/10-6°C-1 | 13.1 | 13.5 | 14.1 | 14.4 | 15.0 | 15.6 | 16.2 |
Karakteristik:
InconelX-750 paduan super paduan nikel-basis.
Di bawah 980°C dengan ketahanan yang baik terhadap korosi dan ketahanan oksidasi
Di bawah 800 °C memiliki kekuatan yang lebih tinggi
Di bawah 540 ° C memiliki ketahanan yang baik terhadap sifat relaksasi, bentuk yang baik dan weldability juga.
Aplikasiadalah mesin pesawat.
Proses pengolahan panas:
Annealing 955-1010°C,dingin air
Pengelasan sebelum pengelasan, pengelupasan 980°C,1h
pengelasan tekanan pengeringan 900°C kelembaban 2 jam
Relaksasi tekanan penggilingan 885 ° C, ± 15 ° C, 24 jam, pendinginan udara.
InconelX-750 sifat mekanik.
σb/MPa≤965
σP0.2/MPa≤550
δ4D/%≥35
dengan kondisi 980 °C ± 15 °C, menahan waktu yang tepat, pendinginan udara atau pendinginan cepat, descaling.
σb/MPa≥1170
σP0.2/MPa≥790
δ4D/%≥15
dengan kondisi + 730 °C ± 10 °C, 8h, pendinginan tungku 55 °C / jam atau pendinginan udara hingga 620 °C ± 10 °C, 8h, pendinginan udara, total waktu penuaan tidak kurang dari 18h
Standar terkait:AMS 5542, AMS 5598
Aplikasi untuk bagian mesin.
-
