EN 10305-4 Pipa Baja Seamless Dingin Diambil Presisi Pipa Seamless Diambil Dingin
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001:2008, TS16949
Nomor Model:
EN10305-4
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
Dapat dinegosiasikan
Kemampuan Penyediaan:
20000 TON / TAHUN
Ringkasan Produk
EN 10305-4 Pipa tarik dingin tanpa jahitan untuk aplikasi presisi Tabung harus diproduksi dari tabung tanpa jahitan yang selesai panas dengan cara menggambar dingin. Metode lain yang cocok untuk pengolahan dingin diizinkan. Tabung harus dikirim dalam kondisi pengiriman +N yang berarti bahwa setelah ...
Rincian produk
Menyoroti:
ditarik tabung mulus dingin
,dingin ditarik tabung
Name:
EN 10305-4 Pipa Dingin Dingin Seamless untuk Aplikasi Presisi
Outer Diameter:
40 - 426 mm
Thickness:
4 - 40 mm
Section Shape:
Bulat
Surface Treatment:
Opsional
Deskripsi Produk
EN 10305-4 Pipa tarik dingin tanpa jahitan untuk aplikasi presisi
Tabung harus diproduksi dari tabung tanpa jahitan yang selesai panas dengan cara menggambar dingin. Metode lain yang cocok untuk pengolahan dingin diizinkan.
Tabung harus dikirim dalam kondisi pengiriman +N yang berarti bahwa setelah operasi penarik dingin terakhir tabung dinormalisasi dalam atmosfer terkontrol.
Ukuran dan toleransi
| Diameter luar yang ditentukan dengan toleransi | Diameter dalam yang ditentukan dengan toleransi | Ketebalan dinding | ||
| 4 | ± 0.08 | 3 | ± 0.15 | 0.5 |
| 2 | 1 | |||
| 5 | ± 0.08 | 3.3 | ± 0.15 | 0.75 |
| 5 | 1 | |||
| 6 | ± 0.08 | 4 | ± 0.12 | 1 |
| 3 | ± 0.15 | 1.5 | ||
| 2 | 2 | |||
| 8 | ± 0.08 | 6 | ± 0.10 | 1 |
| 5 | 1.5 | |||
| 4 | ± 0.15 | 2 | ||
| 3 | 2.5 | |||
| 10 | ± 0.08 | 8 | ± 0.08 | 1 |
| 7 | ± 0.12 | 1.5 | ||
| 6 | ± 0.15 | 2 | ||
| 5 | 2.5 | |||
| 12 | ± 0.08 | 10 | ± 0.08 | 1 |
| 9 | ± 0.10 | 1.5 | ||
| 8 | ± 0.12 | 2 | ||
| 7 | ± 0.15 | 2.5 | ||
| 6 | 3 | |||
| 14 | ± 0.08 | 12 | ± 0.08 | 1 |
| 11 | 1.5 | |||
| 10 | ± 0.10 | 2 | ||
| 9 | ± 0.12 | 2.5 | ||
| 8 | ± 0.15 | 3 | ||
| 15 | ± 0.08 | 13 | ± 0.08 | 1 |
| 12 | 1.5 | |||
| 11 | ± 0.10 | 2 | ||
| 10 | ± 0.12 | 2.5 | ||
| 9 | ± 0.15 | 3 | ||
Komposisi kimia
Sifat mekanik pada suhu kamar
Proses Pengadaan
Pengemasan
