GOST 8734-75 15Cr 30CrMnSi Heavy Steel Steel Tubing Mulus Tabung Baja Dinding Tebal
Rincian produk
thick wall steel pipe
,Tebal dinding Steel Tube
GOST 8734-75 tabung baja tebal dinding tanpa jahitan,10, 20, 35, 45, 10Mn2, 15Cr, 30CrMnSi,Ditarik dingin
GOST 8734-75 tabung baja tebal dinding tanpa jahitan
Jangkauan ukuran:
OD:5-140mm
WT:0.4-12mm
Panjang: 3000mm-12000mm
Karakteristik:
Toleransi OD dan ID yang baik dikontrol sesuai dengan standar teknis
Kualitas stabil
Toleransi:
OD:
D 5 10 mm: ± 0,15 mm
D 11 30 mm: ± 0,30 mm
D 32 mm: ± 0,40 mm
D 51 140 mm: ± 0,8%
WT:
S 0,4 1 mm: ± 0,12 mm
S 1.2 5 mm: ± 10%
S 5.5 12 mm: ± 8%
Catatan:
1.Kelas baja: 10, 20, 35, 45, 10Mn2, 15Cr, 20Cr, 40Cr, 30CrMnSi, 15CrMo sesuai dengan GOST 1050-88, GOST 19281-89, GOST 4543-71.
2.Dimensi dan toleransi sesuai dengan GOST 8734-75.
3.Persyaratan teknis sesuai dengan GOST 8733-74.
4.Panjang dari 1,5 sampai 11,5 m tergantung pada diameter dan ketebalan dinding.
Apa garansi Anda?
1.SO9001:2008 dan sertifikasi TS16949, SGS, BV, TUV atau inspeksi pihak ketiga lainnya tersedia.
2Kualitas tinggi dengan harga yang kompetitif.
3Teknologi canggih, insinyur berpengalaman, sistem mutu ISO untuk jaminan kualitas dan pelacakan.
Apakah Anda memiliki agen atau distributor di negara kita?
1.Kami merekrut agen daerah dan distributor di seluruh dunia, selamat datang untuk mengirim kami surat Anda atau hubungi kami untuk diskusi rinci.
Bagaimana kapasitas produksi Anda?
1.2000 ton kapasitas produksi bulanan, 5000 ton kapasitas perdagangan bulanan
