Carbon DOM Steel Tube ASTM A512 Dingin Diambil Tubing Baja Bulat 1020 1030
Rincian produk
ditarik di atas tabung baja mandrel
,ditarik di atas tabung baja mandrel
Deskripsi produk:
ASTM A512 1020 1030 Cold Drawn Steel Pipe Buttweld Carbon Steel Tube
Kelas baja:
1008, 1010, 1012, 1015 dll
Jangkauan ukuran:
OD: 5-88.9mm
WT: 0.89-12.7mm
Panjang: max12000mm
Ukuran produksi biasa kami 25,4 * 2,11mm, 50,8 * 2,11mm
Komponen kimia:
| Kelas baja | C | Mn | P max | S max |
| 1008 | ≤ 0.10 | 0.30-0.50 | 0.040 | 0.045 |
| 1010 | 0.08-0.13 | 0.30-0.60 | 0.040 | 0.045 |
| 1012 | 0.10-0.15 | 0.30-0.60 | 0.040 | 0.045 |
| 1015 | 0.13-0.18 | 0.30-0.60 | 0.040 | 0.045 |
| 1016 | 0.13-0.18 | 0.60-0.90 | 0.040 | 0.045 |
| 1018 | 0.15-0.20 | 0.60-0.90 | 0.040 | 0.045 |
| 1019 | 0.15-0.20 | 0.70-1.00 | 0.040 | 0.045 |
| 1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.045 |
Kondisi pengiriman:
1. MD (Mandrel Drawn)--Tidak ada perawatan termal akhir
2. SD (Sink Drawn) --Tidak ada perawatan termal akhir
3. MDSR -- Mandrel ditarik dan stres meringankan
4. SDSR--Sink ditarik dan stres meringankan
5. MDSA -- Mandrel ditarik dan lembut Annealed atau normalisasi
6. SDSA--Sink ditarik dan lembut Annealed atau normal
7. NORM-MD-SR--Normalized, Mandrel ditarik, dan stres meringankan
8. NORM-SD-SR--Normalized, Sink ditarik, dan stres meringankan
Karakteristik:
Kualitas Permukaan yang Baik
Toleransi OD dan ID yang baik dikontrol sesuai dengan standar teknis
Kualitas stabil
100% Uji arus Eddy
TORICH Jaminan Kualitas
Proses Produksi:
Tabung harus dibuat oleh proses tungku tapiweld, harus selesai dingin, baik secara eksternal saja ((dilelehkan) atau secara eksternal dan internal ((mandrel ditarik)
Produksi tabung baja:
Uji arus eddy dan uji ultrasonik:
Kemasan:
-
