Diminyaki Silinder Hidrolik Tabung ASTM A519 Carbon Steel Steel Tubing Polos Akhir
Rincian produk
diasah hidrolik tabung silinder
,Hidrolik silinder pipa
Deskripsi produk:
50mm ASTM A519 Baja Karbon Tabung Mekanis Tabung Silinder Hidraulik
ASTM A519 1010 1020 +SRA +N CDS Precision Hydraulic Cylinder Steel Tube
Silinder Minyak Senyawa Karbon dan Baja Alloy Mekanis Tubing ASTM A519
OD: 50-350mm
W.T.:0.5-35mm
L:max12000mm
1. ASTM A519 Silinder Minyak Kabel dan Baja Legasi
2Kelas baja: SAE1010, SAE1020, SAE1026, SAE4130, SAE4140
3Metode produksi: Cold Drawing + Honing + Skiving Roller Bunish
4Pengemasan: Bisa dalam karton atau kotak kayu
Kami menawarkan Cut ke panjang pendek sesuai dengan kebutuhan pelanggan dan gambar.
Kelas dan Komposisi Kimia (%)
| Kelas | C | Mn | P≤ | S≤ | Ya. | Cr | Mo |
| 1008 | ≤ 0.10 | 0.30-0.50 | 0.040 | 0.050 | - | - | - |
| 1010 | 0.08-0.13 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1018 | 0.15-0.20 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
| 1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1025 | 0.22-0.28 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
| 4130 | 0.28-0.33 | 0.40-0.60 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
| 4140 | 0.38-0.43 | 0.75-1.00 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
Sifat mekanik
| Kelas | Kondisi | Titik tarik (Mpa) | Titik hasil (Mpa) | Perpanjangan |
| 1020 | CW | ≥ 414 | ≥ 483 | ≥ 5% |
| SR | ≥ 345 | ≥ 448 | ≥ 10% | |
| A | ≥ 193 | ≥ 331 | ≥ 30% | |
| N | ≥ 234 | ≥ 379 | ≥ 22% | |
| 1025 | CW | ≥ 448 | ≥ 517 | ≥ 5% |
| SR | ≥ 379 | ≥ 483 | ≥ 8% | |
| A | ≥ 207 | ≥ 365 | ≥ 25% | |
| N | ≥ 248 | ≥ 379 | ≥ 22% | |
| 4130 | SR | ≥ 586 | ≥ 724 | ≥ 10% |
| A | ≥ 379 | ≥ 517 | ≥ 30% | |
| N | ≥ 414 | ≥ 621 | ≥ 20% | |
| 4140 | SR | ≥ 689 | ≥ 855 | ≥ 10% |
| A | ≥ 414 | ≥ 552 | ≥ 25% | |
| N | ≥ 621 | ≥ 855 | ≥ 20% |
Bagaimana kapasitas produksi Anda?
1.2000 ton kapasitas produksi bulanan, 5000 ton kapasitas perdagangan bulanan
2Pengiriman yang cepat dan tepat waktu
Bagaimana cara mendapatkan sampelnya?
1.Anda diminta untuk membayar biaya sampel dan biaya kurir dari Cina ke negara Anda; dan sampel gratis adalah sesuai dengan produk seperti ukuran, kelas baja dan kuantitas,Silakan konsultasikan penjualan kami untuk rincian
2Biaya sampel akan dikembalikan saat pesanan dilakukan.
Berapa jangka waktu pembayaranmu?
1.T/T: 30% deposit di muka, saldo 70% dibayarkan sebelum pengiriman
2.30% uang muka, saldo 70% dibayarkan terhadap L / C pada saat melihat
3Setelah negosiasi.
Siapa pelangganmu?
1.Stockists, Distributor, grosirAgen, Pedagang, Pengguna Akhir, dll.
Berapa lama kau akan bereaksi terhadap permintaan kami?
1.Permintaan Anda akan diproses dalam waktu 24 jam pada hari kerja. Kutipan akan dikirim setelah rincian teknis dikonfirmasi oleh pelanggan!
Jika ada pertanyaan tentang keraguan Anda, jangan ragu untuk mengirim email Anda atau hubungi kami!
-
