TORICH BS 3059 Gr.320 SA210 A1 STB340 U Tabung Penukar panas Kondensasi Gas Boiler Tabung Industri Pipa Air Boiler
Rincian produk
baja karbon Tabung
,Penukar panas tabung
TORICH BS 3059 Gr.320 SA210 A1 STB340 U Tube Heat Exchanger Condensing Gas Boiler Tube Industrial Water Pipe Boiler
Detil singkat:
Standar: ASTM/ASME A213
Kelas: T2, T5, T5b, T5c, T9, T11, T12,
T17, T21, T22, T23, T24, T36, T91, T92, T122, T911
Ukuran: (mm)
Jangkauan OD:12.7 mm 400 mm
Ketebalan dinding: 0,8 mm-30 mm
Panjang: Panjang maksimum 25000mm
Deskripsi:
| Standar Eksekutif | ASTM A213 | |
| Bahan-bahan | T2, T5, T5b, T5c, T9, T11, T12, T17, T21, T22, T23, T24, T36, T91, T92, T122, T911 | |
| Ukuran | Diameter luar | 12.7 mm 400 mm |
| Ketebalan dinding | 0.8mm - 30mm | |
| Panjang | Panjang acak tunggal/panjang acak ganda 5m-14m,5.8m, 6m, 10m-12m, 12m atau sesuai permintaan pelanggan | |
| Akhir | Ujung polos/Baved, dilindungi oleh tutup plastik di kedua ujung, kawat potong, alur, bergaris dan kopling, dll. | |
| Pengolahan Permukaan | Bulu, cat hitam, dilapisi, galvanis, anti korosi Lapisan 3PE PP/EP/FBE | |
| Metode Teknis | Ditarik dingin/diekspansi panas | |
| Metode Pengujian | Pengujian arus eddy, pengujian hidrostatik atau pemeriksaan ultrasonik, NDT dan juga dengan pemeriksaan sifat kimia dan fisik | |
| Kemasan | Pipa kecil dalam bundel dengan strip baja yang kuat, besar dalam potongan longgar; Ditutup dengan kantong tenunan plastik; Cocok untuk operasi mengangkat; dimuat dalam wadah 40 kaki atau 20 kaki atau dalam jumlah besar Juga sesuai dengan permintaan pelanggan | |
| Aplikasi | boiler, superheater, dan tabung penukar panas | |
| Asal usul | Cina | |
| Sertifikat | API ISO PED | |
| Pemeriksaan Pihak Ketiga | SGS BV TUV dll. | |
Aplikasi:
Pipa baja boiler tekanan tinggi, rendah dan menengah cocok untuk membuat super-heater, re-heater, water wall, dan economizer di pembangkit listrik skala besar.
Keuntungan Kompetitif:
Produsen pipa dan tabung baja terkemuka di Asia dengan lebih dari 250.000 ton/tahun, > 60% dikirim ke lebih dari 35 negara.Kami bertujuan untuk memproduksi pipa & tabung berkualitas dengan harga yang wajar dan kompetitif, kualitas yang baik untuk pelanggan global kami
-
