OD76.2mm ASTM B163 Monel 400 Pipa
Rincian produk
OD76.2mm Monel 400 Pipe
,ASTM B163 Monel 400 Pipe
,ASTM B163 monel 400 tube
Alloy Monel 400 Nikel Alloy pipa
Detil cepat:
Kelas bahan serupa: UNS:N04400,
DIN: NiCu30Fe W-Nr: 2.4360
GB/T: MCu-28-1.5-1.8
BS: NA 12:Ni68Cu28Fe
Ukuran:
Tabung:OD: 1/2 ∼ -3 ∼ 12.0-76.2 mm
WT:0.02 ̊-0.5 ̊ 0,5-12.0 mm
Panjang: 105ft 32 32mt
Pipa: NPS1/2+-6 21.34-168.3mm
WT:Sch10-Sch80
WT:2.11-12.7mm
Panjang 45ft 14mt
Tabung penukar panas ukuran biasa:
Φ19mmx2mm,Φ25mmx2.5mm和Φ38mmx2.5mm Φ25mmx2mm dan Φ38mmx2.5mm
Menggunakan tabung dengan diameter kecil dapat meningkatkan luas transfer panas per unit volume, struktur kompak, mengurangi konsumsi logam dan meningkatkan koefisien transfer panas.Diperkirakan bahwa area transfer panas dapat ditingkatkan sekitar 40% dan logam dapat disimpan lebih dari 20% dengan mengubah tabung penukar panas dengan diameter yang sama dari Φ 25mm ke Φ 19mm. Tapi resistensi cairan diameter kecil besar, tidak nyaman untuk membersihkan dan mudah untuk memblokir. umumnya, pipa diameter besar digunakan untuk cairan kental atau kotor,sedangkan pipa berdiameter kecil digunakan untuk cairan bersih.
Metode produksi:Ditarik dingin dan digulung dingin
Aplikasi:Penukar panas, tenaga nuklir, insinyur mekanik.
Komposisi kimia:
Ni:63.0menit
C:0.3max
Cu:28.0-34.0
SI:0.5max
Fe:2.5max
S:0.024max
Mn:2.0max
-
