OD114.3mm Nikel N02200 Pipa Paduan Nikel
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
IS09001 ISO14001 TS16949
Nomor Model:
ASTM B163
Properti Perdagangan
Jumlah Pesanan Minimum:
0,5 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L / C, T / T
Kemampuan Penyediaan:
60000 ton per tahun
Ringkasan Produk
Nikel N02200 Pipa/Tabung Detil cepat: OD:3.18-114.3mm WT:0.5-12mm UNS:N02200/W.Nr.2.4060 Nikel 200 Komposisi kimia: Paduan Ni+Co Fe C Mn Ya. Cu S Nikel 200 99 menit 0.4 maksimal 0.15 maksimal 0.35 maksimal 0.30 maksimal 0.25 maksimal 0.25 Maksimal Nikel 200 Sifat fisik Kepadatan 80,89 g/cm3 Titik ...
Rincian produk
Menyoroti:
Pipa paduan nikel N02200
,Pipa Paduan Nikel OD114.3mm
,pipa nikel OD114.3mm
Standard:
Nikel N02200
Material:
Nikel N02200
OD:
3.18-114.3mm
WT:
0,5-12mm
Deskripsi Produk
Nikel N02200 Pipa/Tabung
Detil cepat:
OD:3.18-114.3mm
WT:0.5-12mm
UNS:N02200/W.Nr.2.4060
Nikel 200 Komposisi kimia:
| Paduan | Ni+Co | Fe | C | Mn | Ya. | Cu | S | ||
| Nikel 200 | 99 menit | 0.4 maksimal | 0.15 maksimal | 0.35 maksimal | 0.30 maksimal | 0.25 maksimal | 0.25 Maksimal |
Nikel 200 Sifat fisik
| Kepadatan | 80,89 g/cm3 |
| Titik leleh | 1435-1466°C |
Nikel 200 Sifat mekanik
| Paduan | Kekuatan tarik ((Mpa) Rm N/m2 | Kekuatan output ((Mpa)RP0.2N/mm2 | Perpanjangan A5 % |
| Nikel 200 | 415-585 | 105-310 | 35-55 |
| GB | UNS | SEW VDIUV | BS | AFNOR | |
| Incoloy 800 | NS111 | N08800 | W.Nr.1.4876 X10NiCrAlTi3220 | NA15 | Z8NC32.21 |
| Incoloy 800H | NS112 | N08810 | W.Nr.1.4958 X5NiCrAlTi31-20 | NA15 ((H) | |
| Incoloy 800HT | N08811 | W.Nr.1.4959 X 8 NiCrAlTi32-21 | |||
| Incoloy 825 | NS142 | N08825 | W.Nr.2.4858 NiCr21Mo | NA16 | NC21FeDu |
| Inconel 600 | NS313 | N06600 | W.Nr.2.816 NiCrl5Fe | NA14 | NC15FE |
| Inconel 601 | N06601 | W.Nr.2.4851 NiCr23Fe | NC23FeA | ||
| Inconel 625 | NO6625 | W.Nr.2.4856 NiCr22Mo9Nb
| NA21 | NC22DNb |
