ASTM A268 A268M 05A Tabung Baja Tahan Karat Mulus
Rincian produk
A268M 05A Tabung Stainless Steel Mulus
,ASTM A268 Tabung Stainless Steel Mulus
,A268M 05A Tabung SS Mulus
ASTM A268/A268M-05A Stainless Steel Seamless Tube Tubing Uperheating Steam Tube
Pipa stainless steel banyak digunakan untuk dekorasi arsitektur,
seperti dekorasi lift, pintu mewah, proyek luar ruangan, dekorasi dinding, furnitur, peralatan dapur,
Industri makanan, industri elektronik, peralatan medis, peralatan sanitasi, langit-langit, aula hotel, fasad toko, dll.
Metode Proses
A304:Kode yang ditarik, Bright annealing, Inside bead removing
A316: Kode yang ditarik, Bright annealing
| Komposisi kimia % max | |||||||||
| Bahan | C | Mn | P | S | Ya. | Cr | Tidak | Mo | Ti |
| TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18-20 | 8-11 | - | - |
| TP304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18-20 | 8-12 | - | - |
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16-18 | 10-14 | 2-3 | - |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16-18 | 10-15 | 2-3 | - |
| TP321 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17-19 | 9-12 | - | 0.7 |
Aplikasi:
Boiler, penukar panas,
Kondensor,
tabung uap yang terlalu panas,
Pipa air mendidih
Kemasan:
Setiap tabung dikemas oleh kantong plastik secara individu kemudian dibundel atau disesuaikan
Pengemasan dalam:Tutup di kedua ujung, baja kuat perjalanan pada setiap bungkus,
Kemasan luar: PE Pembungkus luar,
Metode Pengemasan Standar Ekspor ((Bundel dengan pita baja, palet baja),
dikirim dengan kontainer 20' atau 40' atau dalam bulk carrier.
Seperti permintaan pelanggan.
Keuntungan
a) Teknologi canggih mesin tarik dingin
b) Mesin penggilingan canggih
c) Sifat mekanik yang lebih baik
d) Dimensi yang jauh lebih tepat
e) Metode inspeksi yang sempurna dan peralatan inspeksi dll
-
