Titanium / Titanium Alloy Seamless Steel Tube 5 - 89mm Diameter Luar
Rincian produk
stainless steel presisi tubing
,Seamless Carbon Steel tube
TORICH ASTM B338/ASME SB338 tabung titanium dan paduan titanium tanpa jahitan
TORICH ASTM B338/ASME SB338 tabung titanium dan paduan titanium tanpa jahitan
Standar:GB/T3624, GB/T3625, ASTM B338/ASME SB338, ASTM B861/ASME SB861, DIN17861, ASTM A370
Jangkauan ukuran:OD: 5-89mm
WT: 0,2-5,2 mm
Panjang: 15m maksimal
Bahan:Kelas 1, Kelas 2, Kelas 7, Kelas 9, Kelas 12, Kelas 16
Penggunaan:Kondensor dan Penukar Panas
Komposisi Kimia %
| Kelas | N maksimal | C maksimal | H maksimal | Fe maksimal | O maksimal | Sisa | Al | V | Pd | Mo | Cr | Ya. maksimal | S maksimal | Mn maksimal | Cu | lainnya Ers | Tidak | Ti | |
| Setiap maksimal | Total maksimal | ||||||||||||||||||
| Gr.1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| Gr.2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| Gr.3 | 0.05 | 0.08 | 0.015 | 0.30 | 0.35 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| Gr.7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.1 | 0.4 | - | - | 0.12-0.25 | - | - | - | - | - | - | - | - | saldo |
| Gr.9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 0.1 | 0.4 | 2.5-3.5 | 2.0-3.0 | - | - | - | - | - | - | - | - | - | saldo |
| Gr.12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.1 | 0.4 | - | - | - | 0.2-0.4 | - | - | - | - | - | - | 0.6-0.9 | saldo |
| Gr.16 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.1 | 0.4 | - | - | 0.04-0.08 | - | - | - | - | - | - | - | 0.6-0.9 | saldo |
Sifat Mekanis
| Kelas | TS ((Mpa) | YS(Mpa) | E ((%), min |
| Gr.1 | ≥ 240 | 138-310 | 24 |
| Gr.2 | ≥ 345 | 275-450 | 20 |
| Gr.3 | ≥ 450 | 380-550 | 18 |
| Gr.7 | ≥ 345 | 275-450 | 20 |
| Gr.9 | ≥ 620 | ≥ 483 | 15 |
| Gr.12 | ≥ 483 | ≥ 345 | 18 |
| Gr.16 | ≥ 345 | 275-450 | 20 |
Karakteristik:
Konsentrisitas yang baik Keakuratan tinggi
Kualitas permukaan yang baik Kualitas yang stabil
Toleransi OD dan ID yang baik Kerapatan halus
TORICH Jaminan Kualitas
T: Apakah Anda perusahaan dagang atau produsen?
A: Penemu profesional pipa baja, produsen dan penyedia solusi
T: Berapa lama waktu pengiriman Anda?
A: Umumnya adalah 7-14 hari jika barang ada di stok. atau 30-60 hari jika barang tidak ada di stok, dan itu sesuai dengan kuantitas.
T: Apakah Anda menyediakan sampel? apakah itu gratis atau tambahan?
A: Ya, kami dapat menawarkan sampel gratis tetapi Anda perlu membayar biaya pengiriman.
T: Apa syarat pembayaran Anda?
A: Pembayaran <=1000USD, 100% di muka. Pembayaran>=1000USD, 30% T / T di muka, saldo sebelum pengiriman.
Jika Anda memiliki pertanyaan lain, jangan ragu untuk menghubungi kami
