Carbon Molybdenum Alloy Steel Pipe Seamless Untuk Boiler / Superheater
Properti Dasar
Tempat Asal:
Zhejiang, Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001, ISO14001, TS16949
Nomor Model:
ASTM A209
Properti Perdagangan
Jumlah Pesanan Minimum:
5tons
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
50000tons per tahun
Ringkasan Produk
TORICH ASTM A209 Tabung Baja Karbon-Molibdenum Mulus dan Superheater Standar: ASTM A209 / A209M Seamless Carbon-Molybdenum Alloy-Steel Boiler dan Super heater Tubes, Dingin ditarik dan hot rolled tabung baja mulus untuk Boiler dan Super heater Aplikasi: Tabung Boiler dan Superheater Kisaran Ukuran: ...
Rincian produk
Menyoroti:
tabung baja paduan
,baja paduan tabung mulus
Product Name:
Boiler Baja Karbon-Molibdenum Seamless dan Superheater
Keyword:
tabung boiler
Standard:
ASTM A209, ASTM A1016
Surface:
Pengawetan
Material:
Grade T1, Grade T1a, Grade T1b
Shape:
Bulat
OD:
12.7-127mm
WT:
0.9-12.7mm
Length:
4-12 m
Usage:
Tabung Boiler dan Superheater
Deskripsi Produk
TORICH ASTM A209 Tabung Baja Karbon-Molibdenum Mulus dan Superheater
Standar: ASTM A209 / A209M Seamless Carbon-Molybdenum Alloy-Steel Boiler dan Super heater Tubes, Dingin ditarik dan hot rolled tabung baja mulus untuk Boiler dan Super heater
Aplikasi: Tabung Boiler dan Superheater
Kisaran Ukuran: OD: 12.7-127mm WT: 0.9-12.7mm
Tingkat Baja: T1, T1a, T1b
Memproduksi: Bahan baja terbunuh.
Tabung dibuat dengan proses yang mulus baik panas-selesai atau dingin-selesai
Boam Karbon-Molibdenum Paduan-Baja Seamless dan Tabung Pemanas Super
Tabung baja mulus yang digulung dingin dan panas untuk Boiler dan Super heater.
| KOMPOSISI BAJA DAN KIMIA BAJA | ||||||
| Seel Grade | C | M N | P | S | Si | Mo |
| T1 | 0,10-0,20 | 0,30-0,80 | ≤0.025 | ≤0.025 | 0,10-0,50 | 0,44-0,65 |
| T1a | 0,15-0,25 | 0,30-0,80 | ≤0.025 | ≤0.025 | 0,10-0,50 | 0,44-0,65 |
| T1b | ≤0,14 | 0,30-0,80 | ≤0.025 | ≤0.025 | 0,10-0,50 | 0,44-0,65 |
| Peralatan mekanis | |||||
| Seel Grade | Kekuatan tarik ( Mpa ) | Kekuatan luluh ( Mpa ) | δ diperbaiki ( Segmen Pipa S ≥ 8mm vertikal ) | δ diperbaiki ( S < 8mm vertikal ) | δ diperbaiki ( Putaran brilian ) |
| T1 | ≥380 | ≥205 | ≥30 | Lihat Catatan | ≥22 |
| T1a | ≥415 | ≥220 | ≥30 | Lihat Catatan | ≥22 |
| T1b | ≥365 | ≥195 | ≥30 | Lihat Catatan | ≥22 |
| Catatan : S <8mm Pemanjangan vertikal adalah nilai dasar minus 1,5%, per ketebalan dinding minus 0,8mm | |||||
| KEKERASAN | ||
| Seel Grade | HB S ≥ 5.1mm | HRB S ≤ 5.1mm |
| T1 | ≤146 | ≤80 |
| T1a | ≤153 | ≤81 |
| T1b | ≤137 | ≤77 |
Lebih banyak produk
Kondisi pengiriman dan perlakuan panas:
Cold Drawn Seamless dan Hot Rolled Seamless membutuhkan perlakuan panas. Suhu minimum adalah 650 ℃
Jika kondisi Pengiriman adalah anil, anil isotermal, normalisasi + suhu tempering minimum adalah 650 ℃
Tabung yang selesai panas dipanaskan pada suhu 1200 ℉ (650 ℃) atau lebih tinggi.
Dokumen referensi:
Spesifikasi ASTM A450 / A450M untuk Persyaratan Umum untuk Tabung Baja Karbon, Feritik, dan Baja Alen Austenitik
ASTM A941 Terminologi Berkaitan dengan Baja, Baja Tahan Karat, Paduan Terkait dan Ferroalloy
TORICH ASTM A209 Tabung Baja Karbon-Molibdenum Mulus dan Superheater
