tabung baja paduan presisi tinggi Plain End protector Sertifikat ISO9001 TS16949
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
SO9001:2008 ，TS16949
Nomor Model:
ASTM A209 T1 T1a T1b
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
T / T, L / C, D / A, D / P, Western Union, MoneyGram
Kemampuan Penyediaan:
6000ton
Ringkasan Produk
ASTM A209 T1 T1a T1b Tabung baja paduan tanpa jahitan untuk boiler dan superheater Jangkauan ukuran:O.D.: 6-420mm W.T.:1-50mm L: sesuai dengan kebutuhan pelanggan Kelas baja dan komposisi kimia: Elemen T1 T1a T1b Karbon 0.10-0.20 0.15-0.25 0.14max Mangan 0.30-0.80 0.30-0.80 0.30-0.80 Fosfor 0.025 0...
Rincian produk
Menyoroti:
tabung baja paduan
,baja paduan tabung mulus
Product Name:
ASTM A209 T1 Tabung Baja Paduan Seamless
Standard:
ASTM A209
Material:
T1 T1a T1b
Type:
Mulus
Terms Of Trade:
FOB atau CIF
Brand:
UNTUK KAYA
Transportation:
Laut, udara
Certificate:
ISO9001, TS16949
End Protector:
Polos
MTC:
En10204.3.2B
Deskripsi Produk
ASTM A209 T1 T1a T1b Tabung baja paduan tanpa jahitan untuk boiler dan superheater
Jangkauan ukuran:O.D.: 6-420mm W.T.:1-50mm L: sesuai dengan kebutuhan pelanggan
Kelas baja dan komposisi kimia:
| Elemen | T1 | T1a | T1b |
| Karbon | 0.10-0.20 | 0.15-0.25 | 0.14max |
| Mangan | 0.30-0.80 | 0.30-0.80 | 0.30-0.80 |
| Fosfor | 0.025 | 0.025 | 0.025 |
| Sulfur max | 0.025 | 0.025 | 0.025 |
| Silikon | 0.10-0.50 | 0.10-0.50 | 0.10-0.50 |
| Molybdenum | 0.44-0.65 | 0.44-0.65 | 0.44-0.65 |
Sifat Mekanis:
| Elemen | T1 | T1a | T1b |
| Kekuatan tarik min Mpa | 380 | 365 | 415 |
| Kekuatan output min Mpa | 205 | 195 | 220 |
| Elongasi min % | 30 | 30 | 30 |
Pembuatan:
Tabung dibuat dengan proses yang mulus.
Menurut pilihan pabrikan, tabung dapat dilengkapi dengan akhir panas atau akhir dingin.
Uji dan Pemeriksaan:
- Tes Mekanis
- Uji ketegangan
- Uji pembakaran
- Tes perataan
- Tes Kekerasan
- Uji listrik hidrostatik atau tidak merusak
