SAE J526 Satu Dinding Rem Bundy Tabung PVF / Sistem Rem Pelapis Tembaga
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001, TS16949
Nomor Model:
SAE J526
Properti Perdagangan
Jumlah Pesanan Minimum:
1tons
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
T / T, L / C, D / A, D / P, Western Union, MoneyGram
Kemampuan Penyediaan:
60000ton / tahun
Ringkasan Produk
SAE J526 PVF/ Copper Coating Brake System Single Wall Bundy Tube 1. Standar SAE J526 Tabung las rendah karbon EN10305-6 Tabung tarik dingin las dari sistem tenaga hidrolik dan pneumatik ASTM A254 Tabung baja tembaga 2Kelas Baja BHG1, SPCC, SPCD, SPCEN, ST14, ST15, ST16, DC04, DC05, DC06 3Pengolahan ...
Rincian produk
Menyoroti:
pipa baja karbon rendah
,pipa mekanis baja
Product Name:
Tabung Tembok Single Wall
Standard:
SAE J526
Technique:
Pengelasan
Section Shape:
Bulat
Certification:
ISO9001, TS16949
Steel Grade:
BHG1, SPCC, SPCD, SPCEN,
Secondary Or Not:
Non-sekunder
Special Tube:
Sistem otomotif
Surface:
Pelapisan dengan tembaga, seng
Packing:
Dalam koil
Deskripsi Produk
SAE J526 PVF/ Copper Coating Brake System Single Wall Bundy Tube
1. Standar
SAE J526 Tabung las rendah karbon
EN10305-6 Tabung tarik dingin las dari sistem tenaga hidrolik dan pneumatik
ASTM A254 Tabung baja tembaga
2Kelas Baja
BHG1, SPCC, SPCD, SPCEN, ST14, ST15, ST16, DC04, DC05, DC06
3Pengolahan panas
BK atau NBK
4Spesifikasi
| O D/ mm | 4 | 4.2 | 4.76 | 6 | 6.35 | 7.8 | 8 | 9.52 |
| W T | 0.5-1.0mm (0.5-0.7mm WT umum) | |||||||
| Toleransi | ± 0,05mm | |||||||
| Panjang | 180Kg/coil; 700-1000m/coil; per permintaan pelanggan | |||||||
5. Proses Produksi
Pengelasan tabung √ Menggambar dingin (mengurangi diameter) √ Menggelek dalam atmosfer yang dilindungi √ Pembersihan - Deteksi kebocoran √ Pengecoran Seng / Tembaga √ Menjaga tekanan (kekuatan udara) √ Pengemasan
6. Pengolahan Permukaan
| Lapisan | Ketebalan | Durasi uji semprotan garam |
| Tembaga/Sink Putih/Sink Warna | 8 μm | 72 jam |
| PVF | 8μm+20μm | 1000-2000 jam |
| Zinc Hijau Militer | 8 μm | 180 jam |
| GALF | 8μm+20μm | 1000-2000 jam |
| Nylon | 8μm+40μm | 180 jam |
7Pengemasan:Dalam gulungan, dalam kotak kayu dengan kemasan yang layak untuk laut
8. Aplikasi
1) Sistem pengangkut cairan untuk mobil
2) Sistem pengangkut cairan untuk kulkas
3) Kondensator kawat untuk pendingin, showcase
4) Mesin penjual otomatis, mesin es dll.
