17.3mm 19.1mm JIS G3472 STAM390G Mobil Tabung Baja Karbon
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
IS09001 ISO14001 TS16949
Nomor Model:
JIS G3472
Properti Perdagangan
Jumlah Pesanan Minimum:
8 ton atau 5 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L / C, D / A, D / P, T / T, Western Union, MoneyGram
Kemampuan Penyediaan:
60000 ton per tahun
Ringkasan Produk
17.3 mm 19.1 mm JIS G3472 Grade STAM390G Menentukan tabung baja karbon ERW yang digunakan untuk mobil struktur mekanik pipa baja karbonJIS G3445 ((STKM)JIS G3472 ((STAM) 機械、自動車、家具、航空機,dan komponen mesin lainnya. ASTM A512ASTM A513ASTM A519 BS980BS1717BS1775 DIN2391DIN2393DIN 2394 JIS G3472,Standar ...
Rincian produk
Menyoroti:
Tabung Baja Karbon 17.3mm
,Tabung Baja Karbon JIS G3472 STAM390G
,Tabung Baja Karbon Mobil
Material:
IS G3472 STAM290GA, STAM 290GB, STAM 340G, STAM 390G, STAM 440G, STAM 470G, STAM 500G, STAM 440H, ST
OD:
12-127mm
Length:
12m Max
Application:
tabung baja struktur mobil
Deskripsi Produk
17.3 mm 19.1 mm JIS G3472 Grade STAM390G Menentukan tabung baja karbon ERW yang digunakan untuk mobil
| struktur mekanik pipa baja karbon JIS G3445 ((STKM) JIS G3472 ((STAM) | 機械、自動車、家具、航空機,dan komponen mesin lainnya. | ASTM A512 ASTM A513 ASTM A519 | BS980 BS1717 BS1775 | DIN2391 DIN2393 DIN 2394 |
JIS G3472,Standar Industri Jepang Ini menentukan tabung baja karbon las resistansi listrik (ERW) yang digunakan untuk mobil
Diameter luar:15.0mm sampai dan termasuk 127.0mm
Ketebalan dinding:1.0mm sampai dan termasuk 7,0mm
Aplikasi: Tujuan struktur mobil
Grade:JIS G3472 STAM290GA, STAM 290GB, STAM 340G, STAM 390G, STAM 440G, STAM 470G, STAM 500G, STAM 440H, STAM 470H, STAM 500H, STAM 540H Struktur mobil ERWtabung baja
JIS G3472 ERW struktur mobil tabung baja Tabel Komposisi Kimia:
| Kelas baja | Komposisi Kimia% | ||||
| C | Ya. | Mn | P | S | |
| STAM 290GA | 0.12 maksimal. | 0.35 maksimal. | 0.60 maksimal. | 0.035 maksimal. | 0.035 maksimal. |
| STAM 290GB | |||||
| STAM 340G | 0.20 maksimal. | 0.35 maksimal. | 0.60 maksimal. | 0.035 maksimal. | 0.035 maksimal. |
| STAM 390G | 0.25 maksimal. | 0.35 maksimal. | 0.30 ~ 0.90 | 0.035 maksimal. | 0.035 maksimal. |
| STAM 440G | 0.25 maksimal. | 0.35 maksimal. | 0.30 ~ 0.90 | 0.035 maksimal. | 0.035 maksimal. |
| STAM 440H | |||||
| STAM 470G | 0.25 maksimal. | 0.35 maksimal. | 0.30 ~ 0.90 | 0.035 maksimal. | 0.035 maksimal. |
| STAM 470H | |||||
| STAM 500G | 0.30 maksimal. | 0.35 maksimal. | 0.30 ~ 1.00 | 0.035 maksimal. | 0.035 maksimal. |
| STAM 500H | |||||
| STAM 540H | 0.30 maksimal. | 0.35 maksimal. | 0.30 ~ 1.00 | 0.035 maksimal. | 0.035 maksimal. |
JIS G3472 ERW struktur mobil tabel pipa baja Properti mekanik:
| Kelas | Pengangkatan | Kekuatan tarikkgf/? | Kekuatan Hasil kgf/? | Perpanjangan(1) % Percobaan No.1 Percobaan No.2 | Uji pembakaran(2) |
| Ukuran bagian lonceng yang membengkak (D: diameter luar tabung) | |||||
| {N/} | {N/} | Arah bujur | |||
| Kelas G | STAM 290GA | 30 menit. | 18 menit. | 40 menit. | 1.25 D |
| {294} menit. | {177} menit. | ||||
| STAM 290GB | 30 menit. | 18 menit. | 35 menit. | 1.20 D | |
| {294} menit. | {177} menit. | ||||
| STAM 340G | 35 menit. | 20 menit. | 35 menit. | 1.20 D | |
| {343} menit. | {196} menit. | ||||
| STAM 390G | 40 menit. | 24 menit. | 30 menit. | 1.20 D | |
| {392} menit. | {235} menit. | ||||
| STAM 440G | 45 menit. | 31 menit. | 25 menit. | 1.15 D | |
| {441} menit. | {304} menit. | ||||
| STAM 470G | 48 menit. | 33 menit. | 22 menit. | 1.15 D | |
| {471} menit. | {324} menit. | ||||
| STAM 500G | 51 menit. | 36 menit. | 18 menit. | 1.15 D | |
| {500} menit. | {353} menit. | ||||
| Kelas H | STAM 440H | 45 menit. | 36 menit. | 20 menit. | 1.15 D |
| {441} menit. | {353} menit. | ||||
| STAM 470H | 48 menit. | 42 menit. | 18 menit. | 1.10 D | |
| {471} menit. | {412} menit. | ||||
| STAM 500H | 51 menit. | 44 menit. | 16 menit. | 1.10 D | |
| {500} menit. | {431} menit. | ||||
| STAM 540H | 55 menit. | 49 menit. | 13 menit. | 1.05 D | |
| {539} menit. | {481} menit. |
JIS G3472 Ukuran tabung bajaTabel:
| Ditentukan di luarDia. | Ketebalan dinding yang ditentukan(mm) | ||||||||||||||
| (mm) | 1 | 1.2 | 1.6 | 2 | 2.3 | 2.6 | 2.8 | 2.9 | 3.2 | 3.4 | 3.5 | 4 | 4.5 | 5 | 6 |
| 15.9 | - | 0.435 | 0.564 | 0.686 | - | - | - | - | - | - | - | - | - | - | - |
| 17.3 | - | - | - | 0.755 | 0.851 | - | - | - | - | - | - | - | - | - | - |
| 19.1 | 0.446 | 0.53 | 0.69 | 0.843 | 0.953 | - | - | - | - | - | - | - | - | - | - |
| 22.2 | 0.523 | 0.621 | 0.813 | 0.996 | 1.13 | - | - | - | - | - | - | - | - | - | - |
| 25.4 | - | 0.716 | 0.939 | 1.15 | - | 1.5 | - | 1.61 | - | - | - | - | - | - | - |
| 28.6 | - | 0.811 | 1.07 | 1.31 | - | 1.67 | - | - | - | - | - | - | - | - | - |
| 31.8 | 0.76 | 0.906 | 1.19 | 1.47 | 1.67 | - | - | - | 2.26 | - | - | - | - | - | - |
| 34 | - | - | 1.28 | - | 1.8 | - | - | - | 2.43 | - | - | 2.97 | - | - | - |
| 35 | - | 1 | 1.32 | 1.63 | - | - | 2.22 | 2.32 | - | - | - | - | - | - | - |
| 38.1 | 0.915 | 1.09 | 1.44 | 1.78 | 2.03 | - | - | - | - | - | - | - | - | - | - |
| 42.7 | - | 1.23 | 1.62 | 2.01 | 2.29 | 2.57 | - | - | 3.12 | - | 3.38 | - | - | 4.65 | - |
| 45 | 1.08 | 1.3 | 1.71 | 2.12 | 2.42 | 2.71 | - | 3.01 | 3.3 | - | - | - | 4.49 | 4.93 | 5.77 |
| 47.6 | - | 1.37 | 1.81 | - | 2.57 | - | - | 3.2 | - | - | - | - | - | - | - |
| 48.6 | - | 1.4 | 1.85 | 2.3 | 2.63 | - | - | 3.27 | 3.58 | - | - | - | 4.89 | 5.38 | 6.3 |
| 50.8 | - | 1.47 | 1.94 | 2.41 | 2.75 | 3.08 | 3.31 | 3.43 | - | 3.97 | 4.08 | 4.63 | - | - | 6.63 |
| 54 | - | 1.56 | 2.07 | - | 2.93 | 3.29 | 3.54 | 3.65 | - | 4.24 | 4.36 | 4.95 | - | - | - |
| 57 | - | - | 2.19 | - | 3.1 | 3.48 | 3.74 | 3.87 | 4.25 | 4.49 | 4.62 | - | - | - | - |
| 60.5 | - | - | 2.32 | - | 3.3 | 3.71 | - | 4.12 | 4.52 | - | - | 5.59 | - | - | - |
| 63.5 | - | - | 2.44 | - | - | 3.9 | - | - | - | - | - | - | - | - | - |
| 65 | - | - | 2.5 | - | - | - | - | - | 4.88 | - | 5.31 | - | - | - | - |
| 68.9 | - | - | 2.66 | - | 3.78 | - | - | - | - | - | - | - | - | - | - |
| 70 | - | - | 2.7 | - | - | - | - | - | 5.27 | - | 5.74 | - | - | - | - |
| 75 | - | - | 2.9 | - | 4.12 | 4.63 | - | 5.16 | 5.67 | - | |||||
JIS G3472 STAM290GA, STAM 290GB, STAM 340G, STAM 390G, STAM 440G, STAM 470G, STAM 500G, STAM 440H, STAM 470H, STAM 500H, STAM 540H
