61X50 DIN2393 ST52-3 DOM Steel Tube Untuk Silinder Teleskobik Hidrolik
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO 9001 TS 16949
Nomor Model:
DIN2393
Properti Perdagangan
Jumlah Pesanan Minimum:
2 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, T/T
Kemampuan Penyediaan:
5000 ton per tahun
Ringkasan Produk
Tabung baja 61X50 DIN2393 ST52-3 DOM untuk silinder teleskopik hidrolik Detail cepat Bahan:1020 St52-3 Q345B Ukuran: 63*52 80*68 98*85 116*103 135*121 154.5*140 175 kali 159.5 197*180 220*202mm Toleransi OD: (+1,2/1,8mm) Toleransi ID: ((0,-0,2mm) Panjang: sesuai permintaan Anda. Kejujuran ≤0,3...
Rincian produk
Menyoroti:
Tabung Baja DOM Silinder Teleskobik Hidrolik
,Tabung Baja DOM ST52-3
,Tabung Mekanik Dom Presisi
Technique:
Ditarik Dingin
Thickness:
1 - 60 mm
Application:
Pipa Hidrolik
Standard:
ASTM
Section Shape:
Bulat
Alloy Or Not:
Non-paduan
Secondary Or Not:
Non-sekunder
Outer Diameter(Round):
30 - 250 mm
Length:
sesuai dengan permintaan pelanggan
Shape:
bulat
Deskripsi Produk
Tabung baja 61X50 DIN2393 ST52-3 DOM untuk silinder teleskopik hidrolik
Detail cepat
Bahan:1020 St52-3 Q345B
Ukuran:
63*52
80*68
98*85
116*103
135*121
154.5*140
175 kali 159.5
197*180
220*202mm
Toleransi OD: (+1,2/1,8mm)
Toleransi ID: ((0,-0,2mm)
Panjang: sesuai permintaan Anda.
Kejujuran ≤0,3/1000mm
tabung oval ≤0.1
Ketahanan tarik ≥640MPa
Hasil ≥ 550Mpa
Elongasi ≥12%
Kekerasan 80-100HRB -20°C 27J 100% deteksi cacat ultrasonik
St52-3 Pelat baja Analisis kimia
| Elemen kimia | C≤ 16mm maksimal | C> 16mm maksimal | Ya. maksimal | Mn max | P Max. | S Max. |
| %, berdasarkan massa | 0.24 | 0.24 | 0.55 | 1.60 | 0.045 | 0.045 |
Fitur:
Toleransi tinggi
Permukaan yang baik
Kinerja tinggi pada sifat mekanik
Waktu pengiriman cepat
