42CrMo / SCM440 Pipa Baja Paduan Seamless 4140 Poros Presisi
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO 9001 TS16949
Nomor Model:
4140
Properti Perdagangan
Jumlah Pesanan Minimum:
10TON
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, T/T
Kemampuan Penyediaan:
5000 ton per tahun
Ringkasan Produk
Q+T 98X11 4140 Precision Shafting 42CrMo/ SCM440 Alloy Steel Seamless Pipe Detil cepat: Asal usul Cina Nama merek Torich Sertifikat ISO9001 TS16949 Bahan 42CrMo/ SCM440 414042CrMo4 ((1.7225) BS 708M40/708A42/709M40 NF 40CD4/42CD4 ГOCT 38XM Nama produk Q+T 98X11 4140 Precision Shafting 42CrMo/ SCM440 ...
Rincian produk
Menyoroti:
Pipa Seamless Baja Paduan SCM440
,Pipa Seamless Baja Paduan Poros Presisi
,Pipa Baja Paduan 42CrMo Pipa Seamless
Material:
4140
Length:
6-12m
MTC:
EN10304-1
End:
Polos
Production Method:
digulung panas
Heat Treatment:
Ya
Machining:
Ya
Deskripsi Produk
Q+T 98X11 4140 Precision Shafting 42CrMo/ SCM440 Alloy Steel Seamless Pipe
Detil cepat:
| Asal usul | Cina |
| Nama merek | Torich |
| Sertifikat | ISO9001 TS16949 |
| Bahan | 42CrMo/ SCM440 414042CrMo4 ((1.7225) BS 708M40/708A42/709M40 NF 40CD4/42CD4 ГOCT 38XM |
| Nama produk | Q+T 98X11 4140 Precision Shafting 42CrMo/ SCM440 Alloy Steel Seamless Pipe |
| Kapasitas | Pemotongan polishing grinding |
Pengantar dasar
Metode produksi:Membuat gambar dingin, gulung panas.
Tempat Asal: Zhejiang, Cina (Daratan)
Bahan:
| C | Ya. | Mn | P | S | Cr | Mo |
| 0.38 - 0.45 | maksimal 0.4 | 0.6 - 0.9 | maksimal 0.025 | maksimal 0.035 | 0.9 - 1.2 | 0.15 - 0.3 |
| Uni Eropa Keterangan: | Amerika Serikat - | Jerman DIN,WNr | Jepang JIS | Prancis AFNOR | Inggris BS | Italia UNI | Spanyol UNE | Cina GB | Swedia SS | Finlandia SFS | Rusia GOST | Inter ISO | ||||||||||||||||
| 42CrMo4 |
|
|
|
|
|
|
|
|
|
|
|
|
Apa yang bisa kita lakukan:
Penarik dingin
Aplikasi:
42CrMo4 digunakan untuk pembuatan tempa yang membutuhkan kekuatan yang lebih tinggi dan bagian yang lebih besar dimurnikan dan diperkuat daripada baja 35CrMo, seperti gigi besar untuk traksi lokomotif,Gear transmisi supercharger, poros belakang, batang penghubung dan penjepit pegas yang sangat terbebani, 42CrMo4 juga Dapat digunakan untuk sendi pipa pengeboran dan alat memancing di sumur minyak di bawah 2000m.
Fitur:
Kekuatan Tinggi
Kemasan:Kasus kayu atau sesuai dengan kebutuhan klien
Pengiriman:Pengangkutan darat/pengangkutan laut
