Pipa Baja Struktural Paduan Kustom 38CrMoAl ISO 41CrAlMo74 GB / T3077
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO 9001:2008 , TS16949
Nomor Model:
Baja Paduan 38CrMoAl ISO 41CrAlMo74
Properti Perdagangan
Jumlah Pesanan Minimum:
5MT
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, T/T
Kemampuan Penyediaan:
6000MT/Month
Ringkasan Produk
Tipe tabung baja paduan GB/T3077 38CrMoAl ISO 41CrAlMo74 Standar tabung baja struktural GB/T3077: 38CrMoAl ISO: 41CrAlMo74 GOST: 38X2MOA(38XMO(A) DIN: 41CrAlMo7 34CrAlMo5 BS: 905M39 905M31 NF: 40CAD6.12 30CAD6.12 Komposisi kimia:C:0.35 ~ 0.42Si:0.20 ~ 0.45Mn:0.30 ~ 0.60S: ≤ 0.035P: ≤ 0.035Cr:1.35 ~ ...
Rincian produk
Menyoroti:
tabung baja paduan
,seamless alloy steel pipe
Product Name::
tabung baja paduan
Grade::
GB / T3077, 38CrMoAl, ISO41CrAlMo74
Material:
baja paduan
Production:
Selesai Panas dan Selesai Dingin
Deskripsi Produk
Tipe tabung baja paduan GB/T3077 38CrMoAl ISO 41CrAlMo74 Standar tabung baja struktural
GB/T3077: 38CrMoAl
ISO: 41CrAlMo74
GOST: 38X2MOA(38XMO(A)
DIN: 41CrAlMo7 34CrAlMo5
BS: 905M39 905M31
NF: 40CAD6.12 30CAD6.12
Komposisi kimia:
C:0.35 ~ 0.42
Si:0.20 ~ 0.45
Mn:0.30 ~ 0.60
S: ≤ 0.035
P: ≤ 0.035
Cr:1.35 ~ 1.65
Ni: ≤ 0.030
Cu: ≤ 0.030
Mo:0.15 ~ 0.25
Kekuatan tarik:σb (MPa):≥980(100)
Kekuatan output:σs (MPa):≥835(85)
Perpanjangan:δ5 (%):≥14
ψ (%): ≥ 50
Dampak:Akv (J):≥71
αkv (J/cm2):≥ 88(9)
ISO: 41CrAlMo74
GOST: 38X2MOA(38XMO(A)
DIN: 41CrAlMo7 34CrAlMo5
BS: 905M39 905M31
NF: 40CAD6.12 30CAD6.12
Komposisi kimia:
C:0.35 ~ 0.42
Si:0.20 ~ 0.45
Mn:0.30 ~ 0.60
S: ≤ 0.035
P: ≤ 0.035
Cr:1.35 ~ 1.65
Ni: ≤ 0.030
Cu: ≤ 0.030
Mo:0.15 ~ 0.25
Kekuatan tarik:σb (MPa):≥980(100)
Kekuatan output:σs (MPa):≥835(85)
Perpanjangan:δ5 (%):≥14
ψ (%): ≥ 50
Dampak:Akv (J):≥71
αkv (J/cm2):≥ 88(9)
Kekerasan≤ 229HB:30mm
