ASTM A485 Tabung Baja Presisi Dingin / Pipa Baja Untuk Mobil
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO 9001:2008 , BV , ABS , CCS , DNV , GL ,PED
Nomor Model:
ASTM A485
Properti Perdagangan
Jumlah Pesanan Minimum:
5MT
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, T/T
Kemampuan Penyediaan:
15000MT/Month
Ringkasan Produk
ASTM A485 Cold-Drawn Precision Steel Tubes / Pipe Untuk Mobil ASTM A485 Bearing High Hardenability Modifikasi dari High Carbon Bearing Quality Steel Tube Standar Teknis: ASTM A485 Kelas baja: Kelas 1 Kelas 2 Kelas 3 Kelas 4 100CrMnSi4 4 100CrMnSi6 4 100CrMnSi6 6 100CrMo7 100CrMo73 100CrMo74 ...
Rincian produk
Menyoroti:
low carbon steel pipe
,steel mechanical tubing
Material:
Bantalan Steel Tube
Steel Grade:
Kelas 1 Kelas 2 Kelas 3 Kelas 4 100CrMnSi4–4 100CrMnSi6–4 100CrMnSi6–6 100CrMo7 100CrMo7–3 100CrMo7–
O.D.:
5-500mm
W.T.:
0.5-50mm
Length:
max12000mm
Place Of Origin:
Cina
Surface Treatment:
Hot rolled, Annealed
Application:
pembuatan bantalan antifriction
Deskripsi Produk
ASTM A485 Cold-Drawn Precision Steel Tubes / Pipe Untuk Mobil
ASTM A485 Bearing High Hardenability Modifikasi dari High Carbon Bearing Quality Steel Tube
Standar Teknis: ASTM A485
Kelas baja: Kelas 1 Kelas 2 Kelas 3 Kelas 4 100CrMnSi4 4 100CrMnSi6 4 100CrMnSi6 6
100CrMo7 100CrMo73 100CrMo74 100CrMnMoSi8 4 6
Aplikasi:pembuatan bantalan anti-garuk.Ball Bearing, Roller Bearing, Bearing Ring dll.
| Kelas | C | Mn | P (maksimal) | S (maksimal) | Ya. | Cr | Tidak (maksimal) | Ti (maksimal) | Cu (maksimal) | Mo | O (maksimal) | Al (maksimal) |
| Kelas 1 | 0.90 ¢1.05 | 0.90 1.20 | 0.025 | 0.015 | 0.45.0.75 | 0.90 ¢1.20 | 0.25 | 0.0050 | 0.30 | 0.10 (maksimal) | 0.0015 | 0.050 |
| Kelas 2 | 0.85 1.00 | 1.40 1.70 | 0.025 | 0.015 | 0.50-0.80 | 1.40 ¢ 1.80 | 0.25 | 0.0050 | 0.30 | 0.10 (maksimal) | 0.0015 | 0.050 |
| Kelas 3 | 0.95 ¢ 1.10 | 0.65 0.90 | 0.025 | 0.015 | 0.15 ‰0.35 | 1.10 ¢1.50 | 0.25 | 0.0050 | 0.30 | 0.20-0.30 | 0.0015 | 0.050 |
| Kelas 4 | 0.95 ¢ 1.10 | 1.05 1.35 | 0.025 | 0.015 | 0.15 ‰0.35 | 1.10 ¢1.50 | 0.25 | 0.0050 | 0.30 | 0.45-0.60 | 0.0015 | 0.050 |
| 100CrMn Si4?? 4 | 0.93 1.05 | 0.90 1.20 | 0.025 | 0.015 | 0.45.0.75 | 0.90 ¢1.20 | - | - | 0.30 | 0.10 (maksimal) | 0.0015 | 0.050 |
| 100CrMn Si6?? 4 | 0.93 1.05 | 1.00 1.20 | 0.025 | 0.015 | 0.45.0.75 | 1.40 ¢ 1.65 | - | - | 0.30 | 0.10 (maksimal) | 0.0015 | 0.050 |
| 100CrMn Si6?? 6 | 0.93 1.05 | 1.40 1.70 | 0.025 | 0.015 | 0.45.0.75 | 1.40 ¢ 1.65 | - | - | 0.30 | 0.10 (maksimal) | 0.0015 | 0.050 |
| 100CrMo7 | 0.93 1.05 | 0.25 0.45 | 0.025 | 0.015 | 0.15 ‰0.35 | 1.65 ¢1.95 | - | - | 0.30 | 0.15-0.30 | 0.0015 | 0.050 |
| 100CrMo7?? 3 | 0.93 1.05 | 0.60 0.80 | 0.025 | 0.015 | 0.15 ‰0.35 | 1.65 ¢1.95 | - | - | 0.30 | 0.20-0.35 | 0.0015 | 0.050 |
| 100CrMo7?? 4 | 0.93 1.05 | 0.60 0.80 | 0.025 | 0.015 | 0.15 ‰0.35 | 1.65 ¢1.95 | - | - | 0.30 | 0.40-0.50 | 0.0015 | 0.050 |
| 100CrMnM oSi8 ∼4 ∼6 | 0.93 1.05 | 0.80 1.10 | 0.025 | 0.015 | 0.40-0.60 | 1.80 ¢ 2.05 | - | - | 0.30 | 0.50-0.60 | 0.0015 | 0.050 |
