Pipa Baja Superalloy Nikel - Dasar Incoloy A - 286 7.94 G / Cm³ Tabung Baja Paduan

Properti Dasar
Tempat Asal: Cina
Nama merek: Torich
Sertifikasi: CE PED
Nomor Model: Pipa Baja Paduan Baja Incoloy A-286
Properti Perdagangan
Jumlah Pesanan Minimum: 1000KG
Harga: Dapat dinegosiasikan
Ketentuan Pembayaran: L/C, T/T
Kemampuan Penyediaan: 200 ton per tahun
Tag

tabung baja paduan baja mulus

tabung baja paduan

pipa baja paduan mulus
Ringkasan Produk
Pipa baja paduan Incoloy A-286 Karakteristik material: Komposisi kimia: C: ≤ 0,08 Cr:13.5-16.0 Ni:24.0-27.0 Mo:1.00-1.50 Ti:1.75-2.30 Fe: sisa V:0.10-0.50 B:0.001-0.010 Mn:1.00-2.00 Al ≤0.04 Si:≤1.00 P:≤0.030 S:≤0.020 Fe-25Ni-15Cr base superalloy + molibdenum, titanium, aluminium, vanadium Sifat ...

Rincian produk

Menyoroti:

tabung baja paduan

,

baja paduan tabung mulus
Deskripsi Produk

Pipa baja paduan Incoloy A-286

Karakteristik material:

Komposisi kimia:

C: ≤ 0,08 Cr:13.5-16.0 Ni:24.0-27.0 Mo:1.00-1.50 Ti:1.75-2.30 Fe: sisa V:0.10-0.50 B:0.001-0.010 Mn:1.00-2.00 Al ≤0.04 Si:≤1.00 P:≤0.030 S:≤0.020

Fe-25Ni-15Cr base superalloy + molibdenum, titanium, aluminium, vanadium

Sifat fisik:

Densitas 7,94 g/cm3 0,287 lb/in3
Titik leleh 1430°C 2600°F
Koefisien Ekspansi 16,4 μm/m °C (20 - 100°C) 9,1 x 10-6 in/in °F (70 - 212°F)
Modulus Kekakuan 71,5 kN/mm2 10370 ksi
Modulus Elastisitas 205 kN/mm2 29733 ksi

Pengolahan panas Incoloy A-286

Berbagai bahan Pengolahan Panas
Bar, kue 980-1000°C,1-2h,Oil cooler+700-720°C,12-16h,Air cooling
Lembar bergelombang panas, lempeng bergelombang dingin 980-1000°C,Air Cooling+700-720°C,12-16h,Air Cooling
Bar yang ditarik dingin 980-1000°C,1-2h,pembekuan minyak+700-720°C,16h,pembekuan udara
Blank ring 980-990°C,112h,Oil cooler+700-720°C,16h,Air cooling
Pembuatan gambar dingin 980-1000°C,pendingin air atau minyak+700-720°C,16h,pendingin udara

Kekuatan dan daya tahan hasil tinggi

Kekuatan merangkak

Plastisitas pengolahan yang baik dan kinerja las yang memuaskan

Incoloy A-286 digunakan di bidang kedirgantaraan.

Standar terkait:

SAE AMS5731 Baja, tahan korosi dan panas, batang, kawat, tempa, tabung, dan cincin, 15Cr - 25.5Ni - 1.2Mo - 2.1Ti

SAE AMS 5732 Baja, tahan korosi dan panas, batang, kawat, tempa, tabung, dan cincin15Cr - 25.5Ni - 1.2Mo - 2.1Ti - 0.006B - 0.30Velektron yang dapat dikonsumsi Dilelehkan1800 °F (982 °C) Larutan dan Pengolahan Panas Hujan

AMS 5737

AMS 5525

Sama seperti garde:UNSS66286 (AS), ZbNCT25 (Prancis), PQA286 (AS)
