Tipe Penguatan Pangkalan Baja Paduan Baja Super Nikel untuk Bahan Pesawat
Rincian produk
tabung baja paduan
,baja paduan tabung mulus
Bahan pesawat baja paduan pipa Nimonic90
Ukuran:OD:6-530mm WT:0.5-50mm Panjang:1-12m
Aplikasi:
Fitting aerospace, penerbangan, tenaga listrik, petrokimia, pembuatan kapal, mesin, elektronik, perlindungan lingkungan dan industri lainnya.
Fitur material:
Jumlah tinggi kobalt dan berbagai elemen penguat.
Kekuatan tarik dan ketahanan merangkak yang lebih tinggi pada 815-870 °C
Ketahanan yang baik terhadap oksidasi
Ketahanan korosi yang baik
Dalam panas dan dingin bergantian diulang di bawah pengaruh kekuatan kelelahan yang lebih tinggi dan formability baik dan weldability
Komponen kimia
C: 0,13max
Cr: 18.0-21.0
Ni: Margin
Co:15.0-21.0
Al:1.0-2.0
Ti:2.0-3.0
Mn:0.4max
Si:0.8max
P:0.02max
S:0.015max
Ag:0.0005max
Pb:0.002
Bi:0.0001
B:0.020
Cu:0.20
Fe:1.50
Zr:0.15
UNS N070900 NiCr20Co18Ti NCK20TA AMS 5829
Sifat mekanik:
Kekuatan tarik: 800-1000Mpa ((116-145ksi) Dengan kondisi Annealed.
Kekuatan tarik:1200-1400Mpa (174-203ksi) Dengan kondisi Annealed +Aged
Kekuatan tarik:1300-1500Mpa (189-218ksi) Dengan kondisi suhu musim semi
Kekuatan tarik:1500-1800Mpa (218-261ksi) Dengan Spring Temper+Aged
Standar terkait:
WS9 7014-1996 "Nimonic90 paduan kawat ditarik dingin untuk pegas"
WS9 7015.1-1996 "kawat pegas Nimonic90 yang ditarik dingin dan diobati larutan"
WS9 7015.2-1996 "Nimonic90 alloy cold drawn and solution treated spring Biansi"
WS9 7016-1996 "Nimonic90 alloy cold drawn rod"
WS9 7086-1996 "Lembar dan strip bergelombang dingin dari paduan Nimonic90 (keadaan keras)".
WS9 7087-1996 "Lembar dan pita yang digulung dingin dari paduan Nimonic90 (keadaan lunak) "
Bahan serupa: GH90 China.
-
