Min Mpa Extruded Titanium Alloy Steel Pipe, Hot Rolled Steel TubTATA 240
Rincian produk
tabung baja paduan
,seamless alloy steel pipe
GB/T 26058-2010 Titanium dan Titanium Alloy Steel Tube yang Diekstrusi
Tabung Titanium Torich yang Diekstrusi
Nama kelas: TA1 TA2 TA3 TA4 TA8 TA8-1 TA9 TA9-1 TA10 TA18 TC1 TC4
Kondisi pengiriman: Digulingkan panas +Diekstrusi
OD / mm:
25 26 28 30 32 34 35 38 40 42 45 48 50 53 55 60 mm
63 65 70 75 80 85 90 95 100 105 110 115 120 130 mm
140 150 160 170 180 190 200 210 mm
WT / mm: 4 5 8 7 9 10 12 15 18 20 22 25 28 30 mm
Sifat mekanik:
Kondisi: Digulung panas +Diterus
TA1 Kekuatan tarik adalah 240 Mpa min, Elongasi: 24% min
TA2 Kekuatan tarik adalah 400 Mpa min, Elongasi: 20% min
TA3 Kekuatan tarik adalah 450 Mpa min, Elongasi: 18% min
TA9 Kekuatan tarik adalah 400 Mpa min, Elongasi: 20% min
TA10 Kekuatan tarik 485 min Mpa, Elongasi: 18% min
Toleransi OD
| OD | 25 sampai 70 | > 70-100 | > 100-120 | > 120-150 | > 150-170 | > 170-200 | > 200-210 |
| Toleransi | ± 1.0 | ± 1.2 | ± 1.5 | ± 2.0 | ± 2.5 | ± 3.0 | ± 3.5 |
Toleransi pada WT
| WT | 4.5.6 | 7.8.9 | 12.15.18.20 | 22.25.28.30 |
| Toleransi | +1,5/-1 | +2,0/-1.0 | +1.5/-1.0 | +3.0/-2.0 |
Titik pemeriksaan permukaan:
Permukaan luar: bersih, tidak ada retakan.
Dokumen referensi:
GB/T 228 Pengujian ketegangan bahan logam pada suhu lingkungan
GB/T 3620.1 Tingkat titanium dan paduan titanium dan komposisi kimia
GB/T 3620.2 Komposisi kimia produk pengolahan titanium dan paduan titanium Penyimpangan yang diizinkan
GB/T 4698 Metode analisis kimia titanium spons, titanium dan paduan titanium
GB/T 8180 Pengemasan produk pengolahan titanium dan paduan titanium, penandaan, transportasi dan penyimpanan
-
