ASTM A179 U Bend Tabung Penukar Panas Rendah Karbon Tabung Baja Seamless
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001:2008, ISO14001, CE PED, TS16949
Nomor Model:
ASTM A179 ASME A179
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
800-1500 USD/ton
Kemampuan Penyediaan:
20.000 ton / tahun
Ringkasan Produk
ASTM A179 tabung penukar panas baja rendah karbon dan tabung kondensor tanpa jahitan yang ditarik dingin Tabung penukar panas baja rendah karbon yang ditarik dingin tanpa jahitan dan tabung kondensor Aplikasi: Untuk Boiler, Superheater, Penukar panas, Kondensator Tabung lentur U sesuai dengan ...
Rincian produk
Menyoroti:
bend steel tubing
,menekuk tabung baja
Standard:
ASTM A179 ASME A179
Material:
Baja karbon
Type:
U Bending
Production:
Dingin ditarik
Application:
Penukar panas, Kondensor Dingin
Dimension:
OD 15.88-114mm
Deskripsi Produk
ASTM A179 tabung penukar panas baja rendah karbon dan tabung kondensor tanpa jahitan yang ditarik dingin
Tabung penukar panas baja rendah karbon yang ditarik dingin tanpa jahitan dan tabung kondensor
Aplikasi:
- Untuk Boiler,
- Superheater,
- Penukar panas,
- Kondensator
Tabung lentur U sesuai dengan permintaan pelanggan
Rentang ukuran: O.D.:6-168mm W.T.:1-15mm L: sesuai dengan kebutuhan pelanggan.
Kelas baja dan komposisi kimia:
| C | 0.06-0.18 | |
| Mn | 0.27-0.63 | |
| P | ≤ 0.035 | |
| S | ≤ 0.035 |
Sifat Mekanis
Jarak tegangan: min ksi[Mpa] 47[325]
Titik Hasil: min ksi[Mpa] 26[180]
Elongasi: ≥35%
Kekerasan: ≤ 72HRB
